Hocell Digital 5G Cellular Signal Jammer

Hocell digital 5G cellular signal jammer is a plug and play device that can disrupt indoor 2G/3G/4G/5G and WIFI network services, without interference to mobile network providers’ base stations. The jammer has significant higher jamming efficiency compared to traditional analog and digital signal jammers. And it supports remote and local management.

Inquire Now

    By submitting this message, you agree with the privacy policy and the processing of personal data.




    * - required fields

    Features

    Hocell digital 5G cellular signal jammer is a plug and play device that can disrupt mobile phone communication services, including voice, SMS and data. The jammer integrates the main processing unit and all antennas. It supports jamming up to twelve frequency bands in 2G/3G/4G/5G and WIFI network modes.

    With advanced TDD baseband decoding synchronization technology and high-precision switches to distinguish between uplink and downlink time slots, the jamming signals are only transmitted in downlink time slots so as to avoid interference to telecom operators’ base stations. It doesn’t interfere to other electronic products which don’t use cellular signals either. The device supports centralized remote monitoring & management and independent control of each frequency channel. An infrared remote control is also available to power on/off the device locally.

    The jammer is suitable for small and medium indoor spaces such as conference room, court, church, library, school, examination room, cinema, hospital, gas station, oil depots, securities, command center and so on.

    Characteristics

    Support all cellular bands

    The jammer can support all the 2G/3G/4G/5G cellular bands of different mobile network operators and Wi-Fi frequency bands all in one device. And each frequency channel could be controlled independently.

    Plug and play

    The jammer may be used in various scenarios and places, where the cellular frequencies may be different. To make the service fulfillment easy, the jammer is designed to adapt to different radio environment automatically. It supports plug and play, without the necessity of parameter setting.

    No interference to operator’s base stations

    With advanced TDD baseband decoding synchronization technology and high-precision switches to distinguish between uplink and downlink time slots, jamming signals are only transmitted in downlink time slots to avoid interference to TDD base stations. Filtering technologies are employed to minimize spurious emission of all radio frequencies.

    No interference to devices of other frequencies

    Out-of-band rejection of high performance can guarantee no interference to devices using other frequency bands such as UAV.

    Green and smart

    The jammer has significant higher jamming efficiency compared to traditional analog and digital signal jammers. It can achieve better jamming performance with lower RF power transmission.

    Remote and local management

    The signal jammer could be centrally managed through internet and standard TCP/IP protocol or configured locally with a PC.

    Timing function

    As an option on the hardware, the timing function could be supported to set the operation time of the jammer.



    Installation Methods

    Specs

    Item Specification
    Jamming Frequencies
    • 869MHz-880MHz
    • 930MHz-960MHz
    • 1805MHz-1880MHz
    • 1880MHz-1920MHz
    • 2010MHz-2015MHz
    • 2110MHz-2170MHz
    • 2300MHz-2390MHz
    • 2515MHz-2675MHz
    • 3400MHz-3600MHz
    • 2400MHz-2485MHz (WIFI)
    • 5130MHz-5330MHz (WIFI)
    • 5725MHz-5835MHz (WIFI)

    Note: Frequency bands could be customized according to customer’s need

    Max. Output Jamming Power WIFI:30±2dBm, Other systems≥33dBm (carrier signal strength≥-75dBm)
    Jamming Distance >10m (when RSSI≥-70dBm)
    Antenna Integrated directional or omnidirectional antennas
    Interfaces Power, Ethernet (for debugging)
    Indicators Power, Indicator of each RF channel
    Power Input AC 220V to DC 24V power adaptor
    Power Consumption ≤110W
    Function
    • Infrared remote control to power on/off the device;
    • Each channel could be controlled independently.
    Weight >4.5kg
    Dimension 333*245*70mm
