Sentera Double 4K Skyport

Get exceptional crop health insights using plug-and-play, stabilizing gimbal technology. Swap sensor payloads as the growing season progresses for maximum intel.

Inquire Now

      I agree* with the privacy policy and the processing of personal data


    * - required fields

    Features

    Sentera Double 4K Sensors

    The Industry’s Most Versatile Sensor.

    What is the Double 4K?

    The Sentera Double 4K Sensor is the most versatile sensor for crop performance analytics, capturing aerial imagery that can be turned into orthomosaics and detailed analytics.

    Four Variations To Meet Every Use Case

    The Double 4K is available in four variations to deliver the imagery required:

    • Ag+: RGB + NDVI Multispectral Imagery
    • Analytics: Zoom RGB + NDVI Multispectral Imagery
    • Multispectral: 5-band Multispectral Mapping
    • NDVI/NDRE: NDVI + NDRE

    Full-Gimbaled Range Of Motion

    Choose a gimbaled option for full data vertical capture. With Sentera’s Lock-and-Go technology, easily swap sensors.

    Compatible With Industry-Leading Drones

    The Double 4K can easily be integrated on the Sentera PHX and leading DJI drones with the option to complement existing cameras to extend aerial image capture to specific requirements.

    Get Live Video and Still Image Download Plus Full Gimbal Control

    Engineered to integrate seamlessly onto DJI Matrice 200 Series drones, the fully configurable Sentera AGX710 sensor delivers exceptional crop health insights. Using plug-and-play, stabilizing gimbal technology, the AGX710 lets you easily swap payloads and choose from a variety of sensors to augment your operations as the growing season progresses. Now you can quickly capture crop data, developing high-precision spectral index measurements and run deep learning algorithms for more confident decision-making all year.

    On M210 dual-gimbal configurations, combine AGX710 with a ZENMUSE™ XT to add simultaneous thermal-band collection on the same flight. The AGX710 is fully compatible with Sentera FieldAgent™ analysis, reporting and API integrations to offer the best combination of connected and connectionless imaging and analytics capabilities.

    Features and Benefits

    • Full-gimbaled range of motion for full vertical data capture
    • Live-stream RGB and NDVI video
    • Option available for simultaneous collection of 12MP NDVI or NDRE and high-resolution RGB data
    • Easily swap-in and swap-out sensors with Sentera Lock-and-Go technology
    • Seamlessly integrates with FieldAgent® web, mobile and desktop platforms
    • Imagery supports analytics stand and emergence, biomass, nutrition, pest, weed, disease and more

    In the box

    Double 4K Skyport System

    • Double 4K Skyport Sensor with Gimbal

    Optional Matrice 300 Drone

    • M300 Drone
    • 2X Batteries
    • Battery Charger
    • Accessories

    Specification

    Sensors
    • 12.3MP BSI CMOS RGB
    • Sony Exmor R IMX377
    Lenses
    • Standard: 5.4mm
      • HFOV: 60*
      • GSD at 60m: 1.8cm
      • GSD at 120m: 3.5cm
    • Zoom 25mm (Analytics Only):
      • HFOV: 14*
      • GSD at 60m: 0.38cm
      • GSD at 120m: 0.75cm
    Dimensions59mm x 40.9mm x 44.5mm (2.32″ x 1.61″ x 1.75″)
    Weight80 grams
    Power8W typical / 12W maximum
    Frame Rate
    • 12.3MP Stills
    • 4K Ultra HD video at 30fps
    Image Format
    • JPEG
    • 1080p/720p Video
    • H.264 Encoding
    Storage64GB SD card (standard and removable)
    Interfaces
    • Ethernet Serial/UART, USB 3.0 I2C, GPIO
    • Web-based camera configuration
    ControlOpen ICD for triggering and metadata logging over serial or IP, compatible with:

    • PIXHAWK autopilot
    • MAVLink-based systems
    • Customized ICD options available
    Compatible Drones
    • DJI Inspire
    • DJI Matrice
    • DJI Mavic
    • DJI Phantom
    • Sentera PHX

    Download brochure
