The CA50XR series is available in five models, including half-frame and full-frame five-lens oblique cameras. Suitable for fixed-wing and multi-rotor UAVs, the CA50XR series offers high image resolution, five POS information outputs, and good performance at low or high temperatures.
CA504R has a single camera resolution of up to 61 megapixels and a total resolution of up to 305 million pixels.
Even with no GCP, CA504R can achieve 1.5cm GSD and generate high-precision 3D models within 10cm.
It simultaneous outputs of five POS information, minimum exposure interval as low as 0.5s.
CA503R adopts a full-frame back-illuminated sensor with high sensitivity and low noise.
Independent modular design of camera body, control unit, data copy unit make the camera easy to replace and repair.
The camera store data in a high-speed SD card that supports hot-swapping, realizing the preparation of the next sortie within 2 minutes.
Installed with heat dissipation module and 7-way temperature sensor, the camera can be operated at temperatures from -20°C to 65°C.
It can record and output GPS coordinates and attitude angle at the moment of exposure to provide the best 3D mapping solution for you.
By collecting data of the real scene, CA50XR series oblique cameras can not only truly show the detailed texture information of the ground with high precision but also generate a variety of results such as 3D Model, DSM, and DLG through advanced positioning and modeling technologies.
* All performance data in the foregoing pages are theoretical values obtained by JOUAV® internal laboratories through tests carried out under particular conditions. For more information on the specific testing conditions, refer to the aforementioned product details. Actual performance may vary owing to differences in individual product configuration, software versions, application conditions, and environmental factors. All data is subject to actual usage.
