DJI Matrice 30 T | DJI M30T

A New Generation of Commercial Drones

  • 41-min Max Flight Time
  • 15 m/s Wind Resistance
  • 7000 m Service Ceiling
  • 23 m/s Max Speed

Inquire Now

      I agree* with the privacy policy and the processing of personal data


    * - required fields

    Features

    DJI Matrice 30T drone

    The DJI M30T drone is equipped with a variety of high-performance sensors, are lightweight and portable, and are resistant to the effects of weather. The DJI RC PLUS enterprise remote control, as well as the newly enhanced DJI Pilot 2 flight app, are included to improve piloting efficiency and flight safety. The Matrice 30 Series (M30 or M30T) comes with a DJI RC Plus, two TB30 Intelligent Flight Batteries, one BS30 Intelligent Battery Station, and the aircraft storage case.

    Unrivaled aerial intelligence captures everything

    The DJI M30T combines a laser rangefinder with wide-angle, zoom, and thermal cameras (M30T only), allowing you to collect aerial data as needed.Safe and Reliable

    On all six sides of the aircraft, reliable and secure Dual-vision and ToF sensors are mounted, ensuring the aircraft’s and your mission’s safety. Any oncoming crewed aircraft in the area will be detected by the built-in ADS-B receiver.

    Enhanced Transmission

    Thanks to four built-in antennae, OcuSync 3 Enterprise offers triple-channel 1080p video transmission and faultless switching between input sources, even in tough settings. Your connection will be strengthened by the DJI Cellular Module, an optional 4G dongle that enables for stable video transmission in tough or remote business circumstances.

    Lightweight and portable

    Because of its compact and collapsible design, the M30 Series is easy to pack, transport, and deploy.

    BS30 Intelligent Battery Station

    A smart, portable solution with many charging choices is offered to meet your mission requirements. The charger can simultaneously charge four pairs of TB30 Intelligent Flight Batteries and one pair of RC Plus batteries, with each pair taking under 30 minutes to charge from 20% to 90%.

    Intelligent Flight Battery TB30

    Each battery has self-heating for cold circumstances, hot-swapping for quick turnarounds, and 400 charge cycles for increased operational efficiency.

    DJI Cellular Mobile

    The DJI Cellular Module establishes a 4G-based communication link between the drone and the controller, as well as allowing the controller to connect to the internet.

    Specification

    Aircraft

    Dimensions
    (unfolded, excl. propellers)
    470×585×215 mm (L×W×H)
    Dimensions (folded)365×215×195 mm (L×W×H)
    Diagonal Wheelbase668 mm
    Weight (incl. two batteries)3770 ± 10 g
    Max Takeoff Weight3998 g
    Operation Frequency[1]2.4000-2.4835 GHz; 5.725-5.850 GHz
    Transmitter Power (EIRP)2.4 GHz: <33 dBm (FCC); <20 dBm (CE/SRRC/MIC)
    5.8 GHz: <33 dBm (FCC/SRRC); <14 dBm (CE)
    Hovering Accuracy
    (windless or breezy)
    Vertical: ±0.1 m (Vision System enabled); ±0.5 m (N-mode with GPS); ±0.1 m (RTK)
    Horizontal: ±0.3 m (Vision System enabled); ±1.5 m (N-mode with GPS); ±0.1 m (RTK)
    RTK Positioning Accuracy
    (fixed RTK enabled)
    1 cm+1 ppm (horizontal)
    1.5 cm+1 ppm (vertical)
    Max Angular VelocityPitch: 150°/sec.; Yaw: 100°/sec.
    Max Tilt Angle35° (N-mode and Forward Vision System enabled: 25°)
    Max Ascent/Descent Speed6 m/s, 5 m/s
    Max Tilt Descent Speed7 m/s
    Max Horizontal Speed23 m/s
    Max Service Ceiling Above Sea Level (without other payload)5,000 m (with 1671 propellers)
    7,000 m (with 1676 propellers)
    Max Wind Resistance15 m/s
    12 m/s during taking off and landing
    Max Hover Time [2]36 min
    Max Flight Time[2]41 min
    Motor Model3511
    Propeller Model1671
    1676 High Altitude (not included)
    Ingress Protection Rating[3]IP55
    GNSSGPS+Galileo+BeiDou+GLONASS
    (GLONASS is supported only when RTK module is enabled)
    Operating Temperature-20° to 50° C (-4° to 122° F)

    Gimbal

    Angular Vibration Range±0.01°
    Controllable RangePan: ±90°
    Tilt: -120° to +45°
    Mechanical RangePan: ±105°
    Tilt: -135° to +60°
    Roll: ±45°

    Zoom Camera

    Sensor±0.01°
    Controllable Range1/2″ CMOS, Effective pixels: 48M
    LensFocal length: 21-75 mm (equivalent: 113-405 mm)
    Aperture: f/2.8-f/4.2
    Focus: 5 m to ∞

    Wide Camera

    Sensor±0.01°
    Controllable Range1/2″ CMOS, Effective pixels: 12M
    LensDFOV: 84°
    Focal length: 4.5 mm (equivalent: 24 mm)
    Aperture: f/2.8
    Focus: 1 m to ∞

    Thermal Camera

    Thermal ImagerUncooled VOx Microbolometer
    LensDFOV: 61°
    Focal length: 9.1 mm (equivalent: 40 mm)
    Aperture: f/1.0
    Focus: 5 m to ∞
    Infrared Temperature Measurement Accuracy[4]±2°C or ±2% (using the larger value)

    FPV Camera

    Resolution1920×1080
    DFOV161°
    Frame Rate30 fps

    Laser Module

    Vision SystemsInfrared Sensing SystemsTB30 Intelligent Flight BatteryAuxiliary LightsRemote Controller

    Wavelength905 nm
    Max Laser Power3.5 mW
    Single Pulse Width6 ns
    Measurement Accuracy± (0.2 m + D×0.15%)
    D is the distance to a vertical surface
    Measuring Range3-1,200 m (0.5×12 m vertical surface with 20% reflectivity)
    Obstacle Sensing RangeForward: 0.6-38 m
    Upward/Downward/Backward/Sideward: 0.5-33 m
    FOV65° (H), 50° (V)
    Operating EnvironmentSurfaces with clear patterns and adequate lighting (> 15 lux)
    Obstacle Sensing Range0.1 to 10 m
    FOV30°
    Operating EnvironmentLarge, diffuse, and reflective obstacles (reflectivity >10%)
    Capacity5880 mAh
    Voltage26.1 V
    Battery TypeLi-ion 6S
    Energy131.6 Wh
    Net WeightApprox. 685 g
    Operating Temperature-20° to 50° C (-4° to 122° F)
    Storage Temperature20° to 30° C (68° to 86° F)
    Charging Temperature-20° to 40° C (-4° to 104° F)
    (When the temperature is lower than 10° C (50° F), the self-heating function will be automatically enabled. Charging in a low temperature may shorten the lifetime of the battery)
    Chemical SystemLiNiMnCoO2
    Effective Illumination Distance5 m
    Illumination Type60 Hz, solid glow

    Remote Controller

    Screen7.02 inch LCD touchscreen, with a resolution of 1920×1200 pixels, and high brightness of 1200 cd/m2
    Internal BatteryType: Li-ion (6500 mAh @ 7.2 V)
    Charge Type: Supports battery station or USB-C charger maximum rated power 65W (max voltage of 20V)
    Charge Time: 2 hours
    Chemical System: LiNiCoAIO2
    External Battery (WB37 Intelligent Battery)Capacity: 4920 mAh
    Voltage: 7.6 V
    Battery Type: Li-ion
    Energy: 37.39 Wh
    Chemical System: LiCoO2
    Operating Time[5]Internal Battery: Approx. 3 hours 18 min
    Internal Battery + External Battery: Approx. 6 hours
    Ingress Protection Rating[3]IP54
    GNSSGPS+Galileo+BeiDou
    Operating Temperature-20° to 50° C (-4° to 122° F)

    O3 Enterprise

    Operating Frequency[1]2.4000-2.4835 GHz, 5.725-5.850 GHz
    Max Transmission Distance (unobstructed, free of interference)15 km (FCC); 8 km (CE/SRRC/MIC)
    Max Transmission Distance (with interference)Strong Interference (urban landscape, limited line of sight, many competing signals): 1.5-3 km (FCC/CE/SRRC/MIC)
    Medium Interference (suburban landscape, open line of sight, some competing signals): 3-9 km (FCC); 3-6 km (CE/SRRC/MIC)
    Weak Interference (open landscape abundant line of sight, few competing signals): 9-15 km (FCC); 6-8 km (CE/SRRC/MIC)
    Transmitter Power (EIRP)2.4 GHz: <33 dBm (FCC); <20 dBm (CE/SRRC/MIC)
    5.8 GHz: <33 dBm (FCC); <14 dBm (CE); <23 dBm (SRRC)

    Wi-Fi

    ProtocolWi-Fi 6
    Operating Frequency[1]2.4000-2.4835 GHz; 5.150-5.250 GHz; 5.725-5.850 GHz
    Transmitter Power (EIRP)2.4 GHz: <26 dBm (FCC); <20 dBm (CE/ SRRC/MIC)
    5.1 GHz: <26 dBm (FCC); <23 dBm (CE/ SRRC/MIC)
    5.8 GHz: <26 dBm (FCC/SRRC); <14 dBm(CE)

    Bluetooth

    ProtocolBluetooth 5.1
    Operating Frequency[1]2.4000-2.4835 GHz
    Transmitter Power (EIRP)<10 dBm

    BS30 Intelligent Battery Station

    Dimensions353×267×148 mm
    Net Weight3.95 kg
    Compatible Battery TypeTB30 Intelligent Flight Battery
    WB37 Intelligent Battery
    Input100-240 VAC, 50/60 Hz
    OutputTB30 Battery Port: 26.1 V, 8.9 A (supported up to two outputs simultaneously)
    WB37 Intelligent Battery: 8.7 V, 6 A
    Output Power525 W
    USB-C portMax. output power of 65 W
    USB-A portMax. output power of 10 W (5 V, 2 A)
    Power Consumption (when not charging battery)< 8 W
    Output Power (when warming up battery)Approx. 30 W
    Operating Temperature-20° to 40° C (-4° to 104° F)
    Ingress Protection Rating[3]IP55 (with the cover closed properly)
    Charging Time[6]Approx. 30 min (charging two TB30 batteries from 20% to 90%)
    Approx. 50 min (charging two TB30 batteries from 0% to 100%)
    Protection FeaturesAnti-Backflow Protection
    Short Circuit Protection
    Over Voltage Protection
    Over Current Protection
    Temperature Protection

    Other

    Footnotes
    1. 5.8 and 5.1GHz frequencies are prohibited in some countries. In some countries, the 5.1GHz frequency is only allowed for use indoors.
    2. The maximum flight time and the hover time were tested in a lab environment and is for reference only.
    3. This protection rating is not permanent and may reduce over time after long-term use.
    4. Infrared temperature measurement accuracy was tested in a lab environment and is for reference only.
    5.  The maximum operating time was tested in a lab environment and is for reference only.
    6. The charging time was tested in a lab environment at room temperature. The value provided should be used for reference only.
