    Features

    DJI AGRAS T25 redefines standards for compact agricultural drones. Light and nimble, DJI AGRAS T25 can easily be handled by one person. It can carry a spraying payload up to 20 kg or a spreading payload up to 25 kg. DJI AGRAS T25 is equipped with Front and Rear Phased Array Radars, a Binocular Vision System, and a high resolution FPV gimbal camera. DJI AGRAS T25 supports multiple missions, from surveying to spraying and spreading and excels across a variety of terrains.

    Light and Nimble

    • Foldable and simple for solo operation
    • Small for easy takeoff and landing

    Spray or Spread

    • 20 kg spraying tank[1], 16 L/min flow rate[3]
    • 25 kg spreading tank[1], 72 kg/min flow rate[4]

    Signal Stability

    • Offline operations
    • 2 km O3 Transmission[8]
    • Optional DJI Relay

    All Scenario Adaptability

    • Fully automatic and manual operation
    • Orchard Mode
    • Variable Rate Application

    Multidirectional Obstacle Sensing

    • Multidirectional Obstacle Avoidance
    • Terrain Following up to 50°

    Four Sprinkler Kit (Optional)

    • Reverse Directional Spray During Flight
    • 4-sprinkler spraying, flow rate 24 L/min

    Foldable, Flexible, Functional

    DJI AGRAS T25 adopts a lightweight, foldable design. Optimized for solo operations, its unfolded dimensions have been reduced by 21% compared with its predecessor[11]. Transport, fold, takeoff, and land with flexibility.

    Additional Sprinklers to Simplify Spraying

    DJI AGRAS T25 can be equipped with an additional pair of centrifugal sprinklers for four-sprinkler spraying[12]. When flying manually, use Reverse Directional Spray to simplify operations without having to make turns. DJI AGRAS T25 is equipped with a high-resolution FPV gimbal camera which enables viewing the surrounding environment in real time for safer operations.

    High Rate, Atomized Spray, Leak Free

    DJI AGRAS T25’s Dual Atomizing Spraying System provides an ultra-large flow rate of up to 16 L/min (2-sprinkler spraying). It produces uniform and fine spray droplets, and does not leak. DJI AGRAS T25 can be equipped with an additional pair of centrifugal sprinklers, increasing flow rate to 24 L/min (4-sprinkler spraying) for operations that require high application volume, increasing spraying scope, operation efficiency, and leaf coverage.

    Spread with Speed

    DJI AGRAS T25’s new spreader and spiral channel spinning disk significantly improve spreading efficiency and smoothness.

    Tested for reliability, durability and safety

    Spraying and spreading operations are frequent, intense, and take place in complex environments. DJI AGRAS T25 has passed hundreds of reliability tests and its main body is durable to help ensure safe operation.

    Double your peace of mind with Binocular Vision and Dual Radar

    DJI AGRAS T25 is equipped with front and rear Active Phased Array Radars with double the number of RF channels[18] for higher detection precision. Together they enable Multidirectional Obstacle Sensing[6], elevating operating safety. Two sets of Binocular Vision sensors enable DJI AGRAS T25 to accurately sense terrain and depict obstacles in detail, for automatic obstacle bypassing[13] and Terrain Following[13] over steep slopes.

    Specification

    Aircraft

    Weight 25.4 kg (excl. battery)
    32 kg (incl. battery)
    Max Takeoff Weight[1] Max takeoff weight for spraying: 52 kg (at sea level)
    Max takeoff weight for spreading: 58 kg (at sea level)
    Max Diagonal Wheelbase 1925 mm
    Dimensions 2585×2675×780 mm (arms and propellers unfolded)
    1475×1540×780 mm (arms unfolded and propellers folded)
    1050×690×820 mm (arms and propellers folded)
    Hovering Accuracy Range (with strong GNSS signal) RTK enabled:
    Horizontal: ±10 cm, Vertical: ±10 cm
    RTK disabled:
    Horizontal: ±60 cm, Vertical: ±30 cm (radar module enabled: ±10 cm)
    RTK/GNSSOperating Frequency RTK:
    GPS L1/L2, GLONASS F1/F2, BeiDou B1I/B2I/B3I, Galieo E1/E5b, QZSS L1/L2
    GNSS:
    GPS L1, BeiDou B1I, GLONASS F1, Galieo E1, QZSS L1
    Max Configurable Flight Radius 2000 m
    Max Wind Resistance 6 m/s

    Propulsion System – Motors

    Stator Size 100×28 mm
    KV 59 rpm/V
    Power 4600 W/rotor

    Propulsion System – Propellers

    Material Nylon carbon fiber filament
    Dimension 50 inch
    Propeller Rotation Diameter 1270 mm
    Quantity 4

    Dual Atomizing Spraying System – Spray Tank

    Material Plastic (HDPE)
    Volume 20 L
    Operating Payload [1] 20 kg[1]
    Quantity 1

    Dual Atomizing Spraying System – Sprinklers

    Dual Atomizing Spraying System – Delivery PumpsDJI AGRAS T25 Spreading System

    Model LX8060SZ
    Quantity 2
    Nozzle Distance 1368 mm(Rear Nozzles)
    Droplet Size 50-500 μm
    Effective Spray Width[2] 4-7 m (at a height of 3 m above the crops)
    Type Impeller pump (magnetic drive)
    Quantity 2
    Single Pump Flow Rate 0-12 L/min
    Max Flow Rate 16 L/min (2 sprinklers)
    24 L/min (4 sprinklers)
    Compatible Material Diameter 0.5-5 mm
    Spread Tank Volume 35 L
    Spread Tank Internal Load [10] 25 kg[1]
    Effective Spraying Width Varies according to material diameter, spinner disk rotational speed, hopper outlet size, and flight altitude. For optimal performance, it is recommended to adjust the corresponding variables to achieve a spreading range of 5-8 meters.

    Phased Array Radar System

    Model RD241608RF (forward phased array radar)
    RD241608RB (rear phased array radar)
    Terrain Follow Max slope in mapping-free operation: 50°
    Altitude detection range: 1-50 m
    Stabilization working range: 1.5-30 m
    Obstacle Avoidance[4] Obstacle sensing range (multidirectional): 1-50 mFOV:
    Forward phased array radar: horizontal 360°, vertical ±45°, upward ±45° (cone)
    Rear phased array radar: vertical 360°, horizontal ±45°
    Working conditions: flying higher than 1.5 m over the obstacle at a horizontal speed no more than 10 m/s and vertical speed no more than 3 m/s.

    Safety limit distance: 2.5 m (distance between the front of propellers and the obstacle after braking)

    Sensing direction: 360° multidirectional sensing

    Binocular Vision System

    Measurement range 0.5-29 m
    Effective Sensing Speed ≤10 m/s
    FOV Horizontal: 90°, Vertical: 106°
    Operating Environment Adequate light and discernible surroundings

    Remote Controller

    Model RM700B
    Operating Frequency[5] 2.4000-2.4835 GHz, 5.725-5.850 GHz
    Max Transmission Distance 7 km (FCC), 5 km (SRRC), 4 km (MIC/CE)
    (unobstructed, free of interference, and at an altitude of 2.5 m)
    Wi-Fi Protocol Wi-Fi 6
    Wi-Fi Operating Frequency [5] 2.4000-2.4835 GHz
    5.150-5.250 GHz
    5.725-5.850 GHz
    Bluetooth Protocol Bluetooth 5.1
    Bluetooth Operating Frequency
    GNSS GPS+Galileo+BeiDou
    Screen 7.02-in LCD touchscreen, with a resolution of 1920×1200 pixels, and high brightness of 1200 cd/m2
    Operating Temperature -20° to 50° C (-4° to 122° F)
    Storage Temperature Range Less than one month: -30° to 45° C (-22° to 113° F)
    One to three months: -30° to 35° C (-22° to 95° F)
    Six months to one year: -30° to 30° C (-22° to 86° F)
    Charging Temperature 5° to 40° C (41° to 104° F)
    Internal Battery Runtime 3 hours 18 minutes
    External Battery Runtime 2 hours 42 minutes
    Charging Type It is recommended to use a locally certified USB-C charger at a maximum rated power of 65 W and maximum voltage of 20 V such as the DJI 65W Portable Charger.
    Charging Time 2 hours for internal battery or internal and external battery (when remote controller is powered off and using a standard DJI charger)

    DB800 Intelligent Flight Battery

    Model DB800 Intelligent Flight Battery
    (BAX702-15500mAh-52.22V)
    Weight Approx. 6.6 kg
    Capacity 15500 mAh
    Nominal Voltage 52.22 V

    D6000i Multifunctional Inverter Generator

    Output Channel 1. DC charging output 42-59.92V/4500W
    2.AC output 230V/1500W or 120V/750W[8]
    Battery Charging Time[11] To fully charge one battery (DB800 battery) takes 9-12 mins
    Fuel Tank Capacity 20 L
    Starting Method Starting the Generator via the One-Button Start Switch
    Max Power of Engine 6000 W
    Fuel Type Unleaded gasoline with RON ≥91 (AKI ≥87) and alcohol content less than 10%(*Brazil: unleaded gasoline with RON ≥ 91 and alcohol content of 27%)
    Reference Fuel Consumption [9] 600 ml/kWh
    Engine Oil Model SJ10W-40

    C8000 Intelligent Charger

    Model Number CHX101-7000
    Dimensions 300 × 280 × 230 mm
    Weight Approx. 11.5 kg
    Input/Output Input Voltage: 100-240 VAC
    Output Voltage: 59.92V
    Output Current: 100A max
    Charging Time[11] Fully charges a battery in 9 to 12 minutes (DB800 Intelligent Flight Battery)
    Protection Functions Over-temperature, over-voltage, under-voltage, short-circuit, and fan stall protection
    Charging Safety AC wire protection, power wire protection, and charge connector protection

    Relay

    Model RL01-65
    Dimensions 120×110×100 mm
    Weight ≤575 g
    Input Voltage [6] 9 V3 A / 12 V2.5 A / 15 V2 A
    Power Consumption 9 W (SRRC), 12 W (FCC)
    Capacity 6500 mAh
    Operating Time 4 hours
    Operating Frequency [5] 2.4000-2.4835 GHz
    5.725-5.850 GHz
    Max Transmission Distance 5 km (SRRC), 4 km (MIC/KCC/CE), 7 km (FCC)
    (unobstructed, free of interference, and at a flight altitude of 2.5 m)
    Charging Time 2 hours and 20 minutes (when using a standard DJI charger)
    IP Rating [6] IP55

    Definition

    [1] Data was measured at sea level. The payload weight is greatly affected by the ambient temperature and altitude. The payload weight needs to be reduced by 5 kg for every 1,000m increase in altitude. The DJI Agras app will recommend the payload weight according to the current status and surroundings of the aircraft. When adding materials, the maximum weight should not exceed the recommended value, otherwise flight safety may be compromised.
    [2] The spray width of the spraying system depends on the operating scenario and demand for coverage evenness.
    [3] The spread width of the spreading system depends on the operating scenario and demand for coverage evenness.
    [4] The effective sensing range and its ability to avoid and bypass obstacles will vary depending on the ambient light, rain, fog, and the material, position, shape, and other properties of the obstacles. Downward sensing mainly assists in Terrain Follow and Altitude Hold. The sensing in other directions is used for Obstacle Avoidance.
    [5] 5.8 GHz frequency is unavailable in some contries. Check local regulations for more information.
    [6] Use chargers or external power supplies that meet the specifications. Otherwise, the device may not work normally.
    [7] The protection rating may be reduced due to improper use and damage caused by external forces or environmental factors.
    [8] The actual power and voltage may vary according to local regulations.
    [9] Measured using RON 92 gasoline at near sea level with an ambient temperature of 25°C, while charging at 9 kW.
    [10] The DJI Agras app will intelligently recommend the payload weight limit for the spread tank according to the current status and surroundings of the aircraft. DO NOT exceed the recommended payload weight limit when adding material to the spread tank. Otherwise, the flight safety may be affected.
    [11]Factors impacting charging time: Altitude of the charging station; Charging cable meets requirements for fast charging; Battery cell’s temperature is in the range of 15° to 70° C (59° to 158° F)
